Garbage Collection (GC) in the JVM – Optimization and Configuration
Objective
Reduce GC (Garbage Collection) pauses in Java applications by choosing the right garbage collector (G1, ZGC, Shenandoah) and configuring the JVM to balance latency, throughput, and memory usage.
What is Garbage Collection?
The Garbage Collector in the JVM:
- Identifies unused (unreferenced) objects
- Frees up memory they occupy
- Can introduce pause times if misconfigured, affecting performance
Why It Matters for Performance
In systems such as:
- Real-time applications (games, finance)
- High-throughput systems (web apps, microservices)
- Low-latency systems (Kafka, databases, event processing)
A poorly configured GC can:
- Trigger long "stop-the-world" pauses
- Cause CPU spikes
- Degrade user experience and system responsiveness
Types of Garbage Collectors
| Collector | Since | Advantages | Disadvantages | When to Use |
|---|---|---|---|---|
| Serial GC | Java 1.2 | Simple | Long pauses | Small apps, development |
| Parallel GC | Java 1.4 | High throughput | Long pauses | Batch jobs, throughput-focused apps |
| G1 GC | Java 9 | Predictable pauses, balanced | Not ultra-low latency | Web servers, general purpose |
| ZGC | Java 11+ | Ultra-low latency (<10 ms) | Less tuning flexibility | Low-latency systems (finance, APIs) |
| Shenandoah | Java 12+ | Similar to ZGC, low latency | Less portable (Red Hat) | Real-time, low-latency apps |
How to Choose the Right GC
| Goal | Recommended Collector |
|---|---|
| Balanced performance | G1 GC |
Ultra-low latency (<10ms) | ZGC or Shenandoah |
| Max throughput (batch) | Parallel GC |
JVM Configuration Examples
G1 GC (Balanced)
-XX:+UseG1GC
-XX:MaxGCPauseMillis=200
-XX:InitiatingHeapOccupancyPercent=45
-XX:+ParallelRefProcEnabled
-Xms2g -Xmx4g
MaxGCPauseMillis: Target max pause durationInitiatingHeapOccupancyPercent: Threshold to trigger GC
ZGC (Ultra-low latency)
-XX:+UseZGC
-Xmx4g -Xms4g
- Suitable for very low-latency needs
- No tuning required
- Requires Java 11+
Recommended Monitoring Tools
| Tool | Purpose |
|---|---|
| JVisualVM / JConsole | View GC events and memory usage live |
GC Logs (-Xlog:gc*) | Detailed analysis of GC behavior |
| Java Flight Recorder | Low-overhead JVM profiling |
| Prometheus + Grafana | Real-time JVM metrics visualization |
Common Mistakes to Avoid
| Mistake | Consequence |
|---|---|
| Ignoring GC logs | Cannot analyze or debug GC behavior |
| Using wrong GC for the workload | Unnecessary long pauses |
| Incorrect heap sizing | Too small → frequent GC; too big → longer scans |
| Excessive object allocation | GC overload (especially young gen) |
Using finalize() | Slows down GC, discouraged in modern Java |
Business Use Case Example
Case: Online PDF Generation System
- Problem: Generates many temporary objects (~100 MB per document)
- Effect: Frequent GC, noticeable user delays
- Solution:
- Switched to G1 GC
- Configured
-XX:MaxGCPauseMillis=150 - Reused memory buffers to avoid GC pressure
- Set up Prometheus + Grafana for JVM monitoring
Further Reading
Summary
- GC is critical to Java application performance and reliability
- Choose the collector that matches your latency or throughput needs
- G1 is a solid general-purpose collector
- ZGC and Shenandoah are best for latency-sensitive systems
- Always monitor GC behavior in production and test under load
